| FRAME MATERIAL |
Kona 6061 Aluminum Butted |
| SIZES |
S, M, L, XL |
| REAR SHOCK |
n/a |
| FORK |
Rockshox 35 Silver R Air 100mm Tapered 110 Spacing |
| CRANKARMS |
FSA E-Bike |
| CHAINRINGS |
36t |
| B/B |
n/a |
| PEDALS |
Kona JS2 |
| CHAIN |
Shimano HG54 |
| FREEWHEEL |
Shimano Deore 11-46t 10spd or Microshift XLE 11-42t 10spd |
| CHAINGUIDE |
n/a |
| F/D |
n/a |
| R/D |
Shimano Deore |
| SHIFTERS |
Shimano Deore |
| BRAKE CALIPERS |
Shimano MT410 |
| FRONT BRAKE ROTOR |
Shimano RT10 180mm (centerlock) |
| REAR BRAKE ROTOR |
Shimano RT10 160mm (centerlock) |
| BRAKE LEVERS |
Shimano MT4100 |
| HEADSET |
FSA No.57BP |
| HANDLEBAR |
Kona XC/BC Riser |
| STEM |
Kona XC |
| SEATPOST |
Kona Thumb w/Offset 31.6mm |
| SEAT CLAMP |
Kona Clamp |
| GRIPS |
Kona Key Grip |
| SADDLE |
WTB Volt |
| FRONT HUB |
Shimano 110x15mm |
| REAR HUB |
Shimano 135x10mm |
| SPOKES |
Stainless 14g |
| RIMS |
WTB ST i27 TCS 2.0 |
| FRONT TIRE |
Schwalbe G-One Allround 29x2.25" |
| REAR TIRE |
Schwalbe G-One Allround 29x2.25" |
| DRIVE UNIT |
Shimano E6100 25KPH |
| BATTERY |
Shimano 630Wh |
| DISPLAY |
Shimano SC-E7000 Display |
| CHARGER |
Shimano STEPS 2A |
| BATTERY LOCK |
Abus |
| PAINT COLOR |
Gloss Metallic Green w/ Matte Black Forest & Indicator Decals |
| EXTRAS |
Rear Rack, Fenders, Busch & Müller Front & Rear Light, Kickstand |
